TLP5772(TP,E

The TLP5772 is a state-of-the-art TP, E optical coupler gate driver designed to meet the demands of modern electronic applications.

Send Inquiry

Add To Inquiry

Description

Technical Parameters

The TLP5772 is a highly efficient and reliable TP, E optical coupler gate driver designed for demanding electronic applications. With a totem pole output configuration, it provides robust signal amplification for high-speed switching and precise gate control. Noteworthy features include a substantial ±2.5 A output peak current, wide -40 to 110℃ operating temperature range, low 3 mA maximum supply current for energy efficiency, and a broad 10 to 30 V supply voltage range for versatile system integration. The device exhibits a rapid 150 ns propagation delay time, ensuring swift switching, and offers exceptional ±35 kV/μs common-mode transient immunity for enhanced stability in electrically noisy environments. Moreover, the TLP5772 prioritizes safety with a minimum 5000 Vrms isolation voltage, making it a comprehensive solution for applications requiring precision, reliability, and efficient power management.

product-1208-857

Related Products:

Mfr Part	TLP5772	TLP5772(D4-TP,E	TLP5772(TP,E
Description	OPTOISO IGBT MOSFET DRIVER	OPTOISO IGBT MOSFET DRIVER	OPTOISO IGBT MOSFET DRIVER
Stock	50000	50000	50000
Product Status	Active	Active	Active
Technology	Optical Coupling	Optical Coupling	Optical Coupling
Number of Channels	1	1	1
Voltage - Isolation	5000Vrms	5000Vrms	5000Vrms
Common Mode Transient Immunity (Min)	35kV/us	35kV/us	35kV/us
Propagation Delay tpLH / tpHL (Max)	150ns, 150ns	150ns, 150ns	150ns, 150ns
Pulse Width Distortion (Max)	50ns	50ns	50ns
Current - Output High, Low	2.5A, 2.5A	2.5A, 2.5A	2.5A, 2.5A
Current - Peak Output	2.5A	2.5A	2.5A
Voltage - Forward (Vf) (Typ)	1.65V	1.65V	1.65V
Current - DC Forward (If) (Max)	8 mA	8 mA	8 mA
Voltage - Output Supply	10V ~ 30V	10V ~ 30V	10V ~ 30V
Operating Temperature	-40°C ~ 110°C	-40°C ~ 110°C	-40°C ~ 110°C
Package / Case	SDIP6(7.5x1.27)	SDIP6(7.5x1.27)	SDIP6(7.5x1.27)
Package	Tape & Reel (TR)	Tape & Reel (TR)	Tape & Reel (TR)

Applications:

• Photovoltaic (PV) Power Conditioning Systems

• AC Servos

• Compact Motor Drivers

• Industrial Sewing Machines

• Industrial Inverters

General:

The TLP5772 consists of an infrared LED and an integrated high-gain, high-speed photodetector and is housed in the 6-pin SO6L package. The TLP5772 is 50 % smaller than the 8-pin DIP package and meets the reinforced insulation class requirements of international safety standards. Therefore the mounting area can be reduced in equipment requiring the safety standard certification. The TLP5772 has an internal faraday shield that provides a guaranteed common-mode transient immunity of ±35 kV/µs. In particular, this photocoupler guarantees operation with a low threshold input current. It allows bufferless direct drive from a microcomputer. In addition, the TLP5772 has rail to rail output, and this enables stable operation and better switching performance in system.
